D&B AUDIO

d&b audiotechnik CCL12 **


	Image for reference only Actual item may look different Click on image for larger view Click on above thumbnails for alternate view

Daily: $60.00

Weekly: $180.00

Quantity: for a period of
day(s) week(s)

Additional Information

System data
Max. sound pressure
with D25/25D
with D40/D80/D90
135 dB
137 dB
Frequency response (-5 dB standard)62 Hz - 18 kHz
Frequency response (-5 dB CUT mode)110 Hz - 18 kHz
Frequency response (-10 dB standard, IEC60268)58 Hz - 18 kHz
Frequency response (-10 dB CUT mode, IEC60268)78 Hz - 18 kHz
Cabinets per D40/D80/D90 (ArrayProcessing)4
Cabinets per D40/D80/D90 (Line or Arc mode)8
Loudspeaker data
Nominal impedance10 ohms
Power handling capacity (RMS/peak 10 ms)400/1200 W
Nominal dispersion angle (horizontal)80°
Splay angle settings0 ... 14° (1° increment)
Components2 x 7" front LF driver
2 x 5" side LF driver
2 x 1.75" HF compression driver
Passive crossover network
ConnectionsNLT4 F/M
Dimensions / weight
Dimensions (h x w x d)8.23 x 23.35 x 14"
209 x 593 x 355 mm
Weight17.6 kg
38,8 lb

* Prices are subject to change.

* Please call or email us for any questions on our d b audiotechnik ccl12 rentals in Grand Cayman.
